Slide with 1 shaft with raised side panels, width 45 cm, mounting height 350 cm
Slide with 1 shaft with raised side panels, width 45 cm, mounting height 350 cmSlide with 1 shaft with raised side panels, width 45 cm, mounting height 350 cmSlide with 1 shaft with raised side panels, width 45 cm, mounting height 350 cm

Slide with 1 shaft with raised side panels, width 45 cm, mounting height 350 cm

Slide made of V2A, sheet thickness 0.3 cm, handrail tube (ø 4.2 cm), initially raised side cheeks, then 20 cm, for drop height over 200 cm, without weld seam in the slide area, 2 fixing straps at the top.
Article no.
3.63235

Dimension

Length cm:635
Width cm:45
Height cm:407

Falling space

Length cm:835
Width cm:420
Height cm:200

Assembly

Floor anchoring:made of steel for screwing on
Play valueImagesCatalogue pageMaintenance manualDWG
Sliding is not only an exciting experience for children, but also a very special pleasure. Combining a slide with other equipment increases the play value. Our particularly stable and easy-to-maintain stainless steel design has a sophisticated profile; the steep start of the slide is followed by a long, soft transition. Raised side walls also allow the maximum permitted free fall height of 2.50 m.
