Caterpillar - Type 04
Unit made of non-impregnated mountain larch, sawn timber heart-separated. Tongue and groove planks made of 4 cm solid wood, highly resilient, no trickling through. Multi-layer board made of three-layer board (3 cm) or five-layer board (4 cm), high dimensional stability, weatherproof glued in accordance with DIN EN 13353:2011. Richter Hercules rope, Ø > 20 mm, made of galvanised six-strand steel ropes, wrapped and glued with polyester yarn, with very good abrasion resistance, firm hold of the sheathing even in the event of punctual damage. Hot-dip galvanised steel chains (V2A / V4A for an extra charge) welded before galvanising, short-linked, without eyelets on the connecting parts, easy to replace and shorten. Posts and sand sieves made of V2A, glass bead blasted. Bell made of brass. Rubber belt textile-reinforced, 8 mm thick. Coloured with solvent-free acrylic paint. Standard rope colour: rainbow
Article no.
5.00025
Dimension
Length cm:385
Width cm:80
Height cm:165
Falling space
Length cm:585
Width cm:350
Height cm:60
Assembly
Floor anchoring:made of steel for screwing on
The caterpillar is a friendly play offer for small children. The harmonious appearance of the figure and the way in which it is possible to play from both sides offer a lively and pleasant basis for smaller playing spaces. The space partitions promote communicative play, but also make it possible to create borders and divisions of the play areas. This caterpillar type is equipped with a turntable, a two-way channel and shovels.
